20KW便携式充电机充电桩
产品功率: 20KW
输入电压: 90-265V
输出电流: 38A
输出电压: 200-750V
产品详情


产品说明/Product introduction

主要特点
Characteristics
  • 我司生产的20KW便携式充电机,输入电压为380V,语音导航,使用简便,额定输出功率20KW,具有防水防尘功能,多重安全防护。

  • 由监控模块、电源模块、防雷单元、电充接口等组成。

  • 采用高性能充电模块,超宽充电范围,超满载工作效率。

  • 体积小,重量轻,外观时尚,可移动,方便快捷,语音导航,操作方便。

  • 亦可根据车辆BMS参数来定制化生产,可定制预约定时充电功能。

  • Input voltage is 380V, voice navigation, easy to use, rated output power is 20KW, with waterproof and dustproof function, multiple safety protection.
  • By monitoring module, power module, lightning protection unit, charging interface, etc.

  • High performance charging module, super wide charging range, super full load working efficiency.

  • Small size, light weight, fashion appearance, mobile, convenient and quick, voice navigation, easy to operate.

  • You can also customize the production according to the BMS parameters of the vehicle, and you can customize the scheduled charging function.


产品参数/Production parameters

项 目/content

参   数/main parameters

产品型号/model

MXPC20750

输入电压范围/Input Voltage

260-475V,380V(TYPE)

输入电流/Input current

40A

输入线长/Input cable lengths

5M线长可定制/5M (CHAdeMO) , 5M (CCS), 5M(GB/T) Customized acceptable

输出功率/Output power

30KW

输出电压范围/Output voltage

200-750V

输出电流/Output current

0-33A

充电枪线长/Output cable lengths

3M线长可定制/Support for customized

效率/Eff.

95%

辅助电源/Auxiliary power

12V/24V

工作温度/Operation temperature

-40~85℃,25℃(TYPE)

存储温度/Storage temperature

-40~85℃,25℃(TYPE)

防护等级/IP

IP43

尺寸大小/Size(mm)

506×161×277

整机重量/Weight(KG)

27KG
